产品名称：JK-24U Multi channel temperature patrol instrument
规格：LA200911138413
产品备注：Multiplex temperature tester
产品类别：Multiplex temperature tester
JK-24u multi-channel temperature patrol instrument product characteristics:
1 、 large screen liquid crystal display (all temperature values display and alarm temperature display) and the perfect combination of measurement parameters, to meet all the requirements of measurement and display of users, the function is more perfect;
2. front panel can be directly connected with the U disk, the temperature data in a certain number of time intervals stored in the U disk, matching computer system software to read the temperature data has been stored in the U disk, draw the temperature curve, at the same time will be saved to the computer data temperature curve;
3. U inventory of the number of time intervals can be set (hour);
4, in the case of tested objects charged, can be live test (isolation voltage 400V, AC), safe and reliable.
5, the scanning speed between the channels can be set (1ms ~ 99m);
6, you can set any temperature, the upper and lower alarm channel (standard), but also all the way to the police.
7, the temperature unit Celsius (Fahrenheit), Fahrenheit (F) can be automatically converted;
8, the same instrument can choose T, J, K thermocouple to meet different temperature range test;
9, the test channel can be arbitrarily set to meet the requirements of measurement and speed;
10, the machine also comes with date and time, the power is still working;
11. The status bar displays the setting parameters in real time, and can also restore the factory setting function in the setting;
12, the uneven channel: 0.5 degrees, the instrument resolution rate of 0.1 degrees, measuring accuracy is better than 0.5;
13 、 thermocouple broken line has automatic detection function;
14, equipped with communication interface (RS232 or RS485); through the communication interface, you can also choose multi-channel temperature host computer test software;
15, the measurement accuracy is better than 0.5;
J : 0 ～ 760℃
K : 0 ～ 1370℃
T : -100 ～ 400℃
JK-XU is a high performance and low price data acquisition device. It can use multi screen LCD display to see multi-channel temperature changes at the same time. It is very suitable for temperature acquisition and temperature recording applications.It has RS232 interface, you can directly upload data to the PC, also has the USB interface, when it is inconvenient to connect with the PC, you can save the measurement data directly to the U disk, and then transfer the data to the PC when needed. It is a semi frame wide mainframe, with a top 64 channel direct slot on its back, a thermocouple to measure, and 1 unlimited expansion slots, which can accept modular combinations.Whether you need only a few simple data logging channels or hundreds of thousands of performance channels, JK-XU can meet your temperature collection requirements at a reasonable price. Contains JK-XU temperature recording software, including JK-XU temperature recording software
The unique design of the JK-XU allows each 8 channels to be configured as one unit in order to achieve maximum flexibility and quick and easy setup within the automatic range conversion.(that is, you can choose 1-8 for K thermocouple, 9-16 for J thermocouple) and change configuration as needed. The back has a maximum 64 channel direct slot and 1 unlimited expansion slots to meet your unique needs. You can buy only what you need at that time, and then add more modules as your application grows.
Free JK-XU software simplifies data collection. JK-XU software can solve this problem if you want PC based data logging capabilities, but you don't want to spend time programming. Using this software, you can set up your tests, collect and archive, manage measurement data, and display and analyze the data and curves in real time.
The familiar spreadsheet environment can be easily configured and controlled for testing, and rich graphics provide many options for displaying your data. In addition, you can easily send data to other applications using JK-XU software for further analysis or to include it in your display and report.
Widely used in household appliances, industrial (circuit board, PCB temperature detection, etc.) temperature testing areas.
JK-Xu multi-channel temperature detector is equipped with large screen liquid crystal display, U disk to save the interface, you can easily measure, display and preserve temperature data, is a suitable for multi-point real-time monitoring and tracking of the instrument. High voltage semiconductor relay is used to scan the input signal to realize high speed scanning, and the noise and service life of traditional relay are eliminated.
Technical characteristics
The upper and lower temperature values of each channel can be set, and the overload sound alarm can be carried out. Large screen liquid crystal display, can simultaneously display multi-channel temperature value, with U disk interface, insert U disk, can mass preservation temperature record data.
Special pole for internal electronic ballast for energy-saving lamp, tube, choke coil, magnetic ring, capacitors and other components of the temperature real-time monitoring charged by the computer at the same time, the temperature changes the whole process to curve record and easy analysis and improvement, to improve the reliability of energy-saving lamps, electronic ballast has played a significant role.
model
channel
living test
Internal storage
U disk
RS232 communicate interface
JK-Xu
8
support 300Ｖ
yes
yes
yes
16
support 300Ｖ
yes
yes
yes
24
support 300Ｖ
yes
yes
yes
32
support 300Ｖ
yes
yes
yes
64
support 300Ｖ
yes
yes
yes
1, temperature range: -100 ~ 1000 DEG c;
2, measuring accuracy: 0~1000 DEG C: + (read numerical * 0.5%+1) DEG c,
-100 to 0 DEG C: + (read numerical * 0.5%+2) DEG c;
3, with high frequency interference function.
4, temperature signal input channel: maximum configuration 8 groups, each group 8 road;
5, sensors: nickel chromium nickel silicon (K) thermocouple (type T, J type can be made specially).
1, power supply: AC, 220V + 10%, 50Hz + 2%;
2, the use of the environment: temperature: -2070 temperature, relative humidity: 20%90%;
3, thermocouple between the maximum potential difference: < 350V (true effective value);
1, dimensions: (L * w * h) 32cm * 27cm * 12cm
2, the whole weight: About 5kg
Warranty: product hosting free, warranty three years.
Standard K thermocouple, each 2 meters long type T thermocouple pictures
Need to lengthen, need advance.
