JK-8U multi temperature testing instrument equipped with large screen LCD display, U disk storage interface, and temperature data can be conveniently measuring display, which is suitable for multipoint real-time monitoring at the same time tracking instrument. The use of high voltage semiconductor relay as a switch input signal, realizes high speed scanning, eliminating the traditional relay brings noise and service life.

技术特性

Technology characteristics

可设定各通道上下限温度值，超限声音报警。大屏幕液晶显示，可同时显示多路温度值具备U盘接口，插入U盘可海量保存温度记录数据。

Each channel can be set upper and lower limit temperature value, overrun alarm. Large screen LCD display, can display temperature value with U disk interface, insert U disk can be mass storage temperature record data.

特别针对灯具、家用电器、电机、电热器具、温控器、变压器、热保护器等行业的制造厂家及质检部门对多点温度场的检测。节能灯、电子镇流器内部的三极管、扼流圈、磁环、电容等元件的温度同时进行带电实时监控，由电脑将整个温升变化过程全部以曲线方式记录下来，便于分析、改进、对提高节能灯、电子镇流器的可靠性起到很大作用。

Especially for lighting, household appliances, motor, electric heater, thermostat, thermal protection, transformer manufacturers such as industry and quality inspection departments of the multi-point temperature detection. Charged real-time monitoring of energy saving lamp electronic ballast, the internal transistor, choke coil, magnetic ring, capacitors and other components of the temperature at the same time, the computer will process all the changes of temperature rise curve to record, for reliability analysis, improvement, to improve the energy-saving lamps, electronic ballast has played a great role.

The characteristics of multi-channel temperature measuring instrument:

1: 多路温度测试软件与仪器配合使用，计算机自动接收测试数据，实现温度记录，存贮和曲线显示，并打印表格及曲线。

With the use of 1: multi temperature testing software and instrument, computer automatic receiving test data, to achieve temperature recording, storing and curve display, and print tables and curves.

2: JK-XU可以设定参数选用1~64 路任意路测量,

2: JK-XU can set the parameters selection of 1~64 channel arbitrary path measurement,

配接不同的热电偶满足不同的温度测量范围；大屏幕液晶显示，各路温度参数和温度曲线显示，（各路温度值全部显示及一路温度报警通道）计算机串行通信直接连接电脑采集数据，软件为专门针对用户多路温度同时使用的特殊要求，既可以同时测一个样品或多个不同样品，或记录多个测试部位名称，也可以不同吋段测一个样品或多个不同样品，可以设定温度

Matched with different thermocouple temperature measurement range to meet different; large screen LCD display, all the parameters of temperature and temperature curve display, (all temperature values are displayed and a temperature alarm channel) computer serial communication directly connected to the computer data acquisition software for special requirements, specific to the user of multi-channel temperature use at the same time, can be measured a sample or multiple samples at the same time, or record the name of multiple test site, can also be different "measuring a sample or a plurality of different samples, the temperature can be set

曲线颜色，有专业设计简繁体中文和英文版本，适合多种不同测试用途需求

Curve color, has a professional design simplified and traditional Chinese and English version, suitable for a variety of different testing requirements

3: 冷端环境温度：测量范围0～60℃

3: cold end temperature measurement range of 0 ~ 60 ℃:

4: 本机还带有日期和时间设定具有定点、巡检功能；巡检时间可设定：1秒～255秒，测量时间间隔可以设定（不少于1秒）；

4: this machine is also provided with a date and time settings, with fixed point inspection function; inspection time can be set: 1 second to 255 seconds, the time interval measurement can be set (less than 1 second);

5: 温度单位摄氏（C）华氏（F）可以自动转换；一台仪器可以选用T J K热电偶

The temperature of 5: degrees Celsius Fahrenheit units (C) (F) can be automatically converted; one instrument can be used T J K thermocouple

6: 测试通道可以任意设定，满足测量的要求和速度；

6: test channel can be set arbitrarily, meet the measurement requirements and speed;

7: 状态栏实时显示设定参数；各通道不均匀度：0.5 ℃

The 7: status bar display setting parameters; each channel is not uniformity: 0.5 ℃

8: 热电偶探头可接触不超过AC250V的带电物体进行测量而不会损坏仪表； 热电偶探头可接触发热体有相关极限，订货时须提出测量温度范围，以提供相应防护材料

8: thermocouple probe can be charged object contact is not more than AC250V were measured and does not damage the instrument; thermocouple probe can contact the heating body is related to the limit, ordering is proposed to measure the temperature range, to provide the corresponding protective material

JK-XU/XA多路温度测试仪适用于灯具、家用电器、电机、电热器具、温控器、变压器、热保护器等行业的制造厂家及质检部门对多点温度现场的检测。

JK-XU/XA multi temperature testing instrument for lighting, household appliances, motor, electric heater, thermostat, thermal protection, transformer manufacturers such as industry and quality inspection departments detection of multi-point temperature field.

注：

Note:

①表中的T J K为探头的型号，温度范围分别为:

In Table 1 T J K is a probe type, temperature range respectively:

J分度号-100～750±℃（0.3%rdg+1.0℃） 解析度：0.1℃

J indexing, -100 to 750 ± ℃ (0.3%rdg+1.0 ℃) resolution: 0.1 ℃

K分度号100～1200±℃（0.3%rdg+1.0℃） 解析度：0.1℃

The K index number 100 ~ 1200 ± ℃ (0.3%rdg+1.0 ℃) resolution: 0.1 ℃

T分度号-100～400±℃（0.3%rdg+1.0℃） 解析度：0.1℃

T indexing, -100 to 400 ± ℃ (0.3%rdg+1.0 ℃) resolution: 0.1 ℃

②曲线：指仪器不要软件在液晶屏幕中实时显示温度曲线并储存在仪器内部，可以通过通讯接口将曲线永久保存在电脑中。

The curve: refers to the instrument not software on the LCD screen display real-time temperature curve and stored in the instrument, can pass the communication interface will be permanently stored in the computer curve.

③数据：指仪器不要软件将温度值以序号、路数、采集时间及对应的温度值储存在仪器中，可以通过通讯接口将数据永久保存在电脑中。<

The data: refers to the instrument not software the temperature value using serial number, number, acquisition time and stored in the instrument and the corresponding temperature, can pass the communication interface data will be permanently stored in the computer. <

仪器出厂每路均配有2米长的测温(耐温250℃)导线，如需加长则按10元/米计算！配的是K型线 为防止突然断电影响测试，建议配UPS电源

Instrument factory each are equipped with 2 meters long temperature (temperature 250 ℃) wire, for longer at 10 yuan / m! With the K line to prevent a sudden power outage impact test, the proposal with UPS power supply
